180
CJ-series Basic I/O Units Section 3-6
CJ1W-
OD261
64-point Transistor Out-
put Unit with Sinking
Outputs
G79-O@C-@ G7TC-OC16 Output Block Input: 24 V DC
Output: Relay
2 Connecting Cables
and 4 I/O Terminals
G70D-SOC16/
VSOC16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: Relay
G70D-FOM16/
VFOM16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: MOS FET
G70A-ZOC16-3 +
Relays
Relay Terminal
Socket (NPN) +
Relays
Input: 24 V DC
Output: Mechani-
cal relay, SSR,
MOS FET (via
relay)
CJ1W-
MD231
16-point 24-V DC Input/
16-point Transistor Out-
put Unit
Inputs:
G79-@C
G7TC-ID16 Input Block Input: 24 V DC
Output: Relay
1 Connecting Cable
and 1 I/O Terminal
G7TC-IA16 Input: 100/
200 V AC
Output: Relay
Outputs:
G79-@C
G7TC-OC16 Output Block Input: 24 V DC
Output: Relay
1 Connecting Cable
and 1 I/O Terminal
G70D-SOC16/
VSOC16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: Relay
G70D-FOM16/
VFOM16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: MOS FET
G70A-ZOC16-3 Relay Terminal
Socket (NPN) +
Relays
Input: 24 V DC
Output: Mechani-
cal relay, SSR,
MOS FET (via
relay)
CJ1W-
MD261
32-point 24-V DC Input/
32-point Transistor Out-
put Unit
Inputs:
G79-I@C-@
G7TC-ID16 Input Block Input: 24 V DC
Output: Relay
1 Connecting Cable
and 2 I/O Terminals
G7TC-IA16 Input: 100/
200 V AC
Output: Relay
Outputs:
G79-O@C-@
G7TC-OC16 Output Block Input: 24 V DC
Output: Relay
1 Connecting Cable
and 2 I/O Terminals
G70D-SOC16/
VSOC16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: Relay
G70D-FOM16/
VFOM16
Output Termi-
nal (Slim)
Input: 24 V DC
Output: MOS FET
G70A-ZOC16-3 Relay Terminal
Socket (NPN) +
Relays
Input: 24 V DC
Output: Mechani-
cal relay, SSR,
MOS FET (via
relay)
Basic I/O Unit Connecting
Cable
I/O Terminal Required for
connection
Model
number
Specifications Model number Type Input voltage/
output type
