271
PLC Setup Section 7-1
Response Monitoring Time
Function Block Communications Instructions
DeviceNet Communications Instruction Response Monitoring Time
Note The number of resends and response monitoring time must be set by the user
in the FB communications instructions settings in the PLC Setup, particularly
when using function blocks from the OMRON FB Library to execute FINS
messages or DeviceNet explicit messages communications. The values set in
this PLC Setup for OMRON FB Library will be automatically stored in the
related Auxiliary Area words A580 to A582 and used by the function blocks
from the OMRON FB Library.
7-1-2-4 Timings Tab Page
Enable Watch Cycle Time Setting
Watch Cycle Time
Address in
Programming
Console
Settings Function Related
flags and
words
New set-
ting’s effec-
tiveness
Word Bit(s)
201 0 to 15 0001 to FFFF (Unit:
0.1 s, 0.1 to 6553.5)
0000: 2 s
A response timeout occurs when no
response is returned within the time set
here for FINS commands executed within a
function block.
A581 Start of oper-
ation
Address in
Programming
Console
Settings Function Related
flags and
words
New set-
ting’s effec-
tiveness
Word Bit(s)
202 0 to 15 0001 to FFFF (Unit:
0.1 s, 0.1 to 6553.5)
0000: 2 s
A response timeout occurs when no
response is returned within the time set
here for explicit messages commands exe-
cuted within a function block.
A582 Start of oper-
ation
Address in
Programming
Console
Settings Function Related
flags and
words
When set-
ting is read
by CPU Unit
Word Bit(
s)
209 15 0: Default
1: Bits 0 to 14
Default: 0
Set to 1 to enable the Watch Cycle Time
Setting in bits 0 to 14. Leave this setting at 0
for a maximum cycle time of 1 s.
A40108
(Cycle Time
Too Long
Flag)
At start of
operation.
(Can’t be
changed dur-
ing opera-
tion.)
Address in
Programming
Console
Settings Function Related
flags and
words
When set-
ting is read
by CPU Unit
Word Bit(s)
209 0 to 14 001 to FA0: 10 to
40,000 ms
(10-ms units)
Default: 001 (1 s)
This setting is valid only when bit 15 of 209
is set to 1. The Cycle Time Too Long Flag
(A40108) will be turned ON if the cycle time
exceeds this setting.
A264 and
A265
(Present
Cycle Time)
At start of
operation
(Can’t be
changed dur-
ing opera-
tion.)
