Specifications Section 4-1
4-1 Specifications
4-1-1 Specifications
Note 1. Do not apply a voltage higher than 600 V to the terminal block when per-
forming withstand voltage test on this Unit.
Item CS1W-DA041 CS1W-DA08V CS1W-DA08C
Unit type CS-series Special I/O Unit
Isolation (See note 1.) Between I/O and PLC signals: Photocoupler
(No isolation between individual I/O signals.)
External terminals 21-point detachable terminal block (M3 screws)
Power consumption 130 mA max. at 5 VDC,
180 mA max. at 26 VDC
130 mA max. at 5 VDC,
180 mA max. at 26 VDC
130 mA max. at 5 VDC,
250 mA max. at 26 VDC
Dimensions (mm)
(See note 2.)
35 x 130 x 126 (W x H x D)
Weight 450 g max.
General specifications Conforms to general specifications for SYSMAC CS-series Series.
Mounting position CS-series CPU Rack or CS-series Expansion Rack
(Cannot be mounted to a C200H Expansion I/O Rack or a SYSMAC BUS Slave Rack.)
Maximum number of Units (See
note 3.)
Depends on the Power Supply Unit.
Data exchange with CPU Units
(See note 4.)
Special I/O Unit Area
CIO 200000 to CIO295915
(Words CIO 2000 to CIO 2959)
Internal Special I/O Unit DM Area
(D20000 to D29599)
Output
specifi-
cations
Number of analog out-
puts
48 8
Output signal ranges
(See note 5.)
1 to 5 V/4 to 20 mA
0 to 5 V
0 to 10 V
–10 to 10V
1 to 5 V
0 to 5 V
0 to 10 V
–10 to 10 V
4 to 20 mA
Output impedance 0.5 Ω max. (for voltage output)
Max. output current (for
1 point)
12 mA (for voltage output)
Maximum permissible
load resistance
600 Ω (current output)
(See note 9.)
--- 600 Ω (current output)
(See note 8.)
Resolution 4,000 (full scale)
Set data 16-bit binary data
Accuracy
(See note 6.)
23±2°C: Voltage output: ±0.3% of full scale
Current output: ±0.5% of full scale
0°C to 55°C: Voltage output: ±0.5% of full scale
Current output: ±0.8% of full scale
D/A conversion time
(See note 7.)
1.0 ms/point max.
Output
func-
tions
Output hold function Outputs the specified output status (CLR, HOLD, or MAX) under any of the following cir-
cumstances.
When the Conversion Enable Bit is OFF. (See note 8.)
In adjustment mode, when a value other than the output number is output during adjust-
ment.
When there is an output setting error or a fatal error occurs at the PLC.
When the CPU Unit is on standby.
When the Load is OFF.
