Specifications Section 6-1
6-1 Specifications
6-1-1 Specifications
Item CS1W-MAD44
Unit type CS-series Special I/O Unit
Isolation Between I/O and PLC signals: Photocoupler
(No isolation between individual I/O signals.)
External terminals 21-point detachable terminal block (M3 screws)
Power consumption 200 mA max. at 5 VDC, 200 mA max. at 26 VDC
Dimensions (mm)
(See note 1.)
35 x 130 x 126 (W x H x D)
Weight 450 g max.
General specifications Conforms to general specifications for SYSMAC CS-series Series.
Mounting position CS-series CPU Rack or CS-series Expansion Rack
(Cannot be mounted to a C200H Expansion I/O Rack or a SYSMAC BUS Slave Rack.)
Maximum number of Units Units per Rack (CPU
Rack or Expansion
Rack)
(See note 2.)
Power Supply Unit Maximum number of Units per Rack
C200HW-PA204
C200HW-PA204S
C200HW-PA204R
C200HW-PD204
3 Units max.
C200HW-PA209R 6 Units max.
Units per basic
system
When C200HW-PA209R Power Supply Units only are used:
6 Units max. × 8 Racks = 48 Units max.
Data exchange with CPU
Units
Special I/O Unit Area
CIO 200000 to
CIO 295915
(Words CIO 2000 to
CIO 2959)
Exchanges 10 words
of data per Unit.
CPU Unit to AnalogI/
O Unit
Analog output
Peak value hold
Conversion Enable
Bit
Analog I/O Unit to
CPU Unit
Analog input
Input disconnection
detection
Alarm flags
Internal Special I/O
Unit DM Area
(D20000 to D29599)
Transmits 100 words
of data per Unit at
power-up or when
the Unit is restarted.
CPU Unit to AnalogI/
O Unit
Input signal conver-
sion enable/disable,
input signal range
setting
Output signal con-
version enable/dis-
able, output signal
range setting
Ratio conversion
function setting, con-
stants
Output status for out-
put hold
Mean value function
setting
