136
Components and Switch Settings Section 4-3
4-3 Components and Switch Settings
Unit number
setting switch
External terminal
block (M3)
External ter-
minal block
mounting
screws
(black M3)
Front
CS1W-DA041
CS1W-DA08V
CS1W-DA08C
Operation mode switch
Backplane connector
Terminal block
Side
Back
