Omron CJ1W-DA08C

186
Wiring Section 5-4
5-4-2 Internal Circuitry
The following diagrams show the internal circuitry of the analog output sec-
tion.
Voltage Output Circuitry
Current Output Circuitry
Internal Configuration
Output
switch and
conversion
circuit
AMP
Voltage
output (+)
Voltage
output (–)
AG (common to all outputs)
Voltage output section
AMP
Current output section
Output
switch
and con-
version
circuit
Current
output (+)
Current
output (
−)
AMP
Indicators/Switch
MPU
OUTPUT
Regulator
Oscillator
Division
CJ-series PLC
EEPROM
RAM ROM
Photocoupler insulation
+24 V
+5 V
−15 V
+15 V
Bus
interface
D/A
converter
Multi-
plexer
and
amplifier
Externally
connected
terminal
Insulation-type
DC-to-DC
converter
External power
supply (24 VDC)
