Omron CJ1W-DA08C

306
Wiring Section 7-4
Current Output Circuitry
Internal Configuration
AMP
AMP
Output
switch
and con-
version
circuit
Current
output (+)
Current
output (–)
Indicators/Switch
MPU
Regulator
Oscillator
Division
CJ-series PLC
EEPROM
RAM
ROM
Photocoupler insulation
OUTPUT
INPUT
5 V
+5 V
−15 V
+15 V
Bus
interface
D/A
converter
A/D
converter
Multi-
plexer
and
amplifier
Multi-
plexer
and
amplifier
Externally
connected
terminal
Insulation-type
DC-to-DC
converter
