Wiring Section 2-4
CS1W-AD161
Internal Configuration
Input (+)
Input (−)
AG (analog 0 V)
AG (common to all inputs)
Input circuit
and
conversion
circuit
250 Ω
1 MΩ
15 kΩ 15 kΩ
15 kΩ 15 kΩ
1 MΩ
Current mode
Bus
interface
Indicators/Switch
MPU
Regulator
Insulation-type
DC-to-DC
converter
Oscillator
Division
CS-series PC
EEPROM
RAM ROM
Multi-
plexer
and
amplifier
A/D
converter
INPUT
Externally
connected
terminal
Photocoupler insulation
