A-11
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from
User Program
The device variables for CJ-series Units that correspond to bits 0 to 15 of 4 words from CIO n+6 to
n+9 are as follows:
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+6 0 *_CnctNdCmd[0] Disconnect/Connect Switch for Node
Address 0 Slave
1 *_CnctNdCmd[1] Disconnect/Connect Switch for Node
Address 1 Slave
2 *_CnctNdCmd[2] Disconnect/Connect Switch for Node
Address 2 Slave
3 *_CnctNdCmd[3] Disconnect/Connect Switch for Node
Address 3 Slave
4 *_CnctNdCmd[4] Disconnect/Connect Switch for Node
Address 4 Slave
5 *_CnctNdCmd[5] Disconnect/Connect Switch for Node
Address 5 Slave
6 *_CnctNdCmd[6] Disconnect/Connect Switch for Node
Address 6 Slave
7 *_CnctNdCmd[7] Disconnect/Connect Switch for Node
Address 7 Slave
8 *_CnctNdCmd[8] Disconnect/Connect Switch for Node
Address 8 Slave
9 *_CnctNdCmd[9] Disconnect/Connect Switch for Node
Address 9 Slave
10 *_CnctNdCmd[10] Disconnect/Connect Switch for Node
Address 10 Slave
11 *_CnctNdCmd[11] Disconnect/Connect Switch for Node
Address 11 Slave
12 *_CnctNdCmd[12] Disconnect/Connect Switch for Node
Address 12 Slave
13 *_CnctNdCmd[13] Disconnect/Connect Switch for Node
Address 13 Slave
14 *_CnctNdCmd[14] Disconnect/Connect Switch for Node
Address 14 Slave
15 *_CnctNdCmd[15] Disconnect/Connect Switch for Node
Address 15 Slave
To Next Page
