Related Manuals
38
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
Related Manuals
The following manuals are related to the NJ-series Controllers. Use these manuals for reference.
Manual name Cat. No. Model numbers Application Description
NJ-series CPU Unit
Hardware User’s Manual
W500 NJ501-@@@@
NJ301-@@@@
Learning the basic specifi-
cations of the NJ-series
CPU Units, including intro-
ductory information,
designing, installation, and
maintenance. Mainly hard-
ware information is pro-
vided.
An introduction to the entire NJ-series system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
Use this manual together with the NJ-series
CPU Unit Software User’s Manual (Cat. No.
W501).
NJ-series CPU Unit Soft-
ware User’s Manual
W501 NJ501-@@@@
NJ301-@@@@
Learning how to program
and set up an NJ-series
CPU Unit. Mainly software
information is provided.
The following information is provided on a Con-
troller built with an NJ501 CPU Unit.
• CPU Unit operation
• CPU Unit features
• Initial settings
• Programming based on IEC 61131-3 lan-
guage specifications
Use this manual together with the NJ-series
CPU Unit Hardware User’s Manual (Cat. No.
W500).
Sysmac Studio Version 1
Operation Manual
W504 SYSMAC-
SE2@@@
Learning about the operat-
ing procedures and func-
tions of the Sysmac Studio.
Describes the operating procedures of the Sys-
mac Studio.
CJ-series DeviceNet
Units Operation Manual
for NJ-series CPU Unit
(This document)
W497 CJ1W-DRM21 Learning about the func-
tions and operating proce-
dures when the CJ-series
DeviceNet Unit is used in
an NJ-series system con-
figuration.
The functions and operating procedures when
the CJ-series DeviceNet Unit is used in an NJ-
series system configuration are described.
DeviceNet Operation
Manual
W267 --- Learning about the com-
munications specifications
and wiring methods com-
mon among the DeviceNet
communications networks.
The communications specifications and wiring
methods common among the DeviceNet com-
munications networks are described.
Please read this manual and familiarize yourself
with the functions and characteristics of the
DeviceNet before use.
DRT2 Series DeviceNet
Slaves Operation Manual
W404 DRT2-ID/OD/
MD32SL(H)(-1)
DRT2-MD16S
DRT2 Series
Learning about the DRT2
Series DeviceNet Slaves.
The types of DRT2 DeviceNet Slaves, the func-
tions, specifications, and operating procedures
are described in details.
GT1 Series DeviceNet
Multiple I/O Terminal
Operation Manual
W348 DRT1-COM
GT1 Series
Learning about the Multiple
I/O Terminal, which is a
type of DeviceNet Slave.
The types of Multiple I/O Terminal, which are
kinds of DeviceNet Slaves, are provided. Also,
their functions, specifications, and operating
procedures are described in details.
CVM1/CV-series and
C200HX/HG/HE/HS
DeviceNet Master Units
Operation Manual
W379
C200HW-DRM21-V1
CVM1-DRM21-V1
Learning about C200H and
CVM1/CV DeviceNet Mas-
ter Units.
The specifications of C200H and CVM1/CV
DeviceNet Master Units, their functions and
operating procedures are described.
CS/CJ Series DeviceNet
Unit Operation Manual
W380
CS1W-DRM21(-V1)
CJ1W-DRM21
Learning about the func-
tions and operating proce-
dure for CS/CJ Series
DeviceNet Units.
The functions and operating procedures when
the CS/CJ Series DeviceNet Unit is used in
CS/CJ series system configuration are
described.
CX-Integrator Ver.2. @
Operation Manual
W464 ---
Learning about the CX-Inte-
grator that is used to set up
the DeviceNet networks
and to make settings.
The operating procedures for CX-Integrator are
described.
