3 Data Exchange with the CPU Unit
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
3-2 Device Variables for CJ-series Unit (Software
Switches, Statuses)
3
3-2-10 Slave Status 2
*_Slav2Sta (Slave Status 2) is used to reference 2 types of information: Master Node Address and
Slave I/O Allocation Status.
Use *_MstrNdAdrSta (Node Address of The Remote Master for Slave Communications) and
*_SlavIOAlocSta (Slave I/O Allocation Status) to reference individual information.
z *_MstrNdAdrSta (Node Address of The Remote Master for Slave
Communications)
This indicates the node address of the remote master for slave communications.
This information is valid when *_Slav1IO2CommSta (Remote I/O Communications for OUT 2/IN 2)
and *_Slav1IO1CommSta (Remote I/O Communications for OUT 1/IN 1) are TRUE in Slave Status
1.
z *_SlavIOAlocSta (Slave I/O Allocation Status)
This indicates the I/O allocation status of the slave.
3-2-10 Slave Status 2
Code Details
16#00 Unit starting up
16#01 Fixed allocation status 1
16#02 Fixed allocation status 2
16#03 Fixed allocation status 3
16#20 User-set allocations with set device variable for CJ-series Unit
16#30 User-set allocations set by CX-Integrator
16#80 Slave function disabled
Name of device variable for
CJ-series Unit
Type R/W Area Function
*_Slav2Sta WORD R Slave Sta-
tus 2
Bits 00 to 07: Master Node Address
Bits 08 to 15: Slave I/O Allocation Status
Default: 16#0000
*_MstrNdAdrSta USINT R Node
Address of
The
Remote
Master for
Slave Com-
munications
This indicates the node address of the
remote master for slave communications.
Data range: 0 to 63
Default: 0
*_SlavIOAlocSta BYTE R Slave I/O
Allocation
Status
This indicates the I/O allocation status of
the slave.
Data range: 16#00 to 03, 16#20, 16#30,
16#80
Default: 16#00
