Manual Configuration
6
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
GT1 Series DeviceNet Multiple I/O Terminal Operation Manual (Cat.
No. 348)
Section Description
Section 1
Multiple I/O Terminal
This section describes the features, system configuration, types of Units and funci-
tons provided by the Multiple I/O Terminals.
Section 2
Hardeare Setup and Operationa
Check
This section describes the operating procedures for the Multiple I/O Terminals by
using examples.
Section 3
Sample Programs
This section provides sample programs to use the Special I/O Units of the Multiple
I/O Terminals.
Section 4
Basic I/O Unit Specifications
This section describes the specifications of the each Basic I/O Unit, terminal arrange-
ments, wiring methods.
Section 5
Special I/O Unit Specifications
This section describes the specifications, terminal arrangements, wiring methods of
the each Special I/O Unit.
Section 6
Communications Timing
This section describes the response time and transmission delay time of the remote
I/O commucnaitions functions.
Section 7
Troublushooting and Maintenance
This section describes the troublushooting and mentainance procedures to take cor-
rective actions for errors and conduct a routine inspection.
Appendices
This section provides the device profiles of Slaves that are required in the multi-ven-
dor environments and gives a list of products including Multiple I/O Terminals and
connected devices.
CVM1/CV-series and C200HX/HG/HE/HS DeviceNet Master Units
Operation Manual (Cat. No. W379)
Section Description
Section 1
Features and System Configuration
This section describes the features of the DeviceNet and the operating procedure for
the DeviceNet Master Unit.
Section 2
Master Unit Components and Instal-
lation
This section describes the component names, functionality and installation of the
DeviceNet Master Units.
Section 3
Remote I/O commucanitons
This section describes the remote I/O master function provided by the DeviceNet
Master Unit.
Section 4
Message Communications
This section describes the message commucniations performed by the DeviceNet
Master Unit.
Section 5
Software Switches and Status Area
This section describes the details on the software switches used to control the
DeviceNet Unit and the status area.
Section 6
Communications Timing
This section describes the communication timing of the DeviceNet Master Unit and
the performances of the remote I/O communciations and message communications.
Section 7
Troubleshooting and Maintenance
This section describes the troublushooting and mentainance procedures to take cor-
rective actions for errors and conduct a routine inspection.
Appendix
This section describes the details on the commands for the message communcia-
tions and the completion codes of the message communications.
