Omron CJ2H-CPU6*-EIP Series - Page 25

7
．
EtherNet/IP Connection Procedure
22
16
SUB3 is displayed on Main
Display.
Press the ZERO/SET Key.
Check that 255 is displayed on
Sub-display.
*The set value here is the third
octet "255" of the subnet mask
255.255.255.0.
*If the value is different, change
the value in the same way as
step 9.
Press the ZERORST/ESC Key.
The first menu shown in this
step is displayed again.
Press the
→
(RIGHT ) Key.
255
17
SUB4 is displayed on Main
Display.
Press the ZERO/SET Key.
Check that 0 is displayed on
Sub-display.
*The set value here is the fourth
octet "0" of the subnet mask
255.255.255.0.
*If the value is different, change
the value in the same way as
step 9.
Press the ZERORST/ESC Key.
The first menu shown in this
step is displayed again.
Press the ZERORST/ESC Key
twice.
0
