EtherNet/IP Connection Procedure
21
14
SUB1 is displayed on Main
Display.
Press the ZERO/SET Key.
Check that 255 is displayed on
Sub-display.
*The set value here is the first
octet "255" of the subnet mask
255.255.255.0.
*If the value is different, change
the value in the same way as
step 9.
Press the ZERORST/ESC Key.
The first menu shown in this
step is displayed again.
Press the
→
(RIGHT ) Key.
255
15
SUB2 is displayed on Main
Display.
Press the ZERO/SET Key.
Check that 255 is displayed on
Sub-display.
*The set value here is the
second octet "255" of the
subnet mask 255.255.255.0.
*If the value is different, change
the value in the same way as
step 9.
Press the ZERORST/ESC Key.
The first menu shown in this
step is displayed again.
Press the
→
(RIGHT ) Key.
255
