Omron CJ2H-CPU6*-EIP Series - Page 48

7
．
EtherNet/IP Connection Procedure
45
7.4.4. Setting the Connections
Associate the tags of the target device (that receives the open request) with the tags of the
originator device (that requests for opening).
1
Select 192.168.250.50 in the
Unregister Device List Field.
Click the Down Arrow Button
that is shown in the dialog box.
2
192.168.250.50 is registered in
the Register Device List Field.
Select 192.168.250.50 and click
New.
3
The Edit Connection Dialog Box
is displayed.
Check that Consume Data
From/Produce Data To is
selected from the pull-down list
of Connection I/O Type.
Set the values listed in the
following table in the Originator
Device and the Target Device
Fields.
■Connection configuration settings
Connection configuration
Set value
Connection I/O Type
Consume Data From
/Produce Data To
Originator Device
Input Tag Set
D10100-[56 Byte]
Connection Type
Multi-cast connection
Output Tag Set
D10000-[24 Byte]
Connection Type
Point to Point connection
Target Device
Output Tag Set
Input_101-[56 Byte]
Input Tag Set
Output_100-[24 Byte]
