EtherNet/IP Connection Procedure
46
4
Check that the settings are
correct.
Click Regist.
5
The Edit Connection Dialog Box
is displayed again. Click Close.
6
The Edit Device Parameters
Dialog Box is displayed again.
Click OK.
7
When the connection is
completed, the registered node
address is displayed under the
device icon of node 50 in the
Network Configuration Pane.
