CP1E CPU Unit Hardware User’s Manual(W479)
Terminology and Notation
Term Description
E-type CPU Unit A basic model of CPU Unit that support basic control applications using instructions such
as basic, movement, arithmetic, and comparison instructions.
Basic models of CPU Units are called “E(S)-type CPU Units” in this manual.
The models of E(S)-type CPU Units are shown below.
CP1E-ED-
CP1E-ESD-
N-type CPU Unit An application model of CPU Unit that supports connections to Programmable Terminals,
inverters, and servo drives.
Application models of CPU Units are called “N(S)-type CPU Units” in this manual.
The models of N(S)-type CPU Units are shown below.
CP1E-ND-
CP1E-NSD-
CP1E-NS1D-
NA-Type CPU Unit An application model of CPU Unit that supports built-in analog and connections to Pro-
grammable Terminals, inverters, and servo drives.
Application models of CPU Units with built-in analog are called “NA-type CPU Units” in
this manual.
CX-Programmer A programming device that applies for programming and debugging PLCs.
The CX-Programmer includes the Micro PLC Edition CX-Programmer (CX-One Lite), the
CX-Programmer (CX-One) and the CX-Programmer for CP1E.
This manual describes the unique applications and functions of the Micro PLC Edition
CX-Programmer version 9.03 or higher/CX-Programmer for CP1E.
“CX-Programmer” refers to the Micro PLC Edition CX-Programmer version 9.03 or
higher/CX-Programmer for CP1E in this manual.
Note E20/30/40(S) and N20/30/40(S) CPU Units are supported by CX-Programmer
version 8.2 or higher. E10/14(S), N14/60(S) and NA20 CPU Units are supported
by CX-Programmer version 9.03 or higher. E60S CPU Units are supported by CX-
Programmer version 9.42 or higher.
