Procedural Flow Section 3-1
3. Select the name of the instance that was registered from the pull-down
menu on the FB Instance Field.
Allocate External I/O to
the Function Block
Refer to 3-2-5 Setting Function Block Parameters Using the Enter Key for
details.
1,2,3... 1. Place the cursor at the position of the input variable or output variable and
press the P Key.
2. Input the source address for the input variable or the destination address
for the output variable.
Set the Function Block
Memory Allocations
(Instance Areas)
Refer to 3-2-6 Setting the FB Instance Areas for details.
1,2,3... 1. Select the instance and select Function Block/SFC Memory - Function
Block/SFC Memory Allocation from the PLC Menu.
2. Set the function block memory allocations.
Printing, Saving, and Reusing Function Block Files
Compile the Function
Block Definition and Save
It as a Library File
Refer to 3-2-12 Compiling Function Block Definitions (Checking Program) and
3-2-16 Saving and Reusing Function Block Definition Files for details.
1,2,3... 1. Compile the function block that has been saved.
2. Print the function block.
3. Save the function block as a function block definition file (.cxf).
4. Read the file into another PLC project.
Transferring the Program to the PLC
Refer to 3-2-17 Downloading/Uploading Programs to the Actual CPU Unit.
Monitoring and Debugging the Function Block
Refer to 3-2-18 Monitoring and Debugging Function Blocks.
