Statement Descriptions Section 5-5
Instance_FB(FB_IN1:=IN1,FB_IN2:=IN2,FB_IN3:=IN3,
FB_OUT1=>OUT1,FB_OUT3=>OUT3)
• Different order of entry:
Instance_FB(EN:=A,FB_IN1:=IN1,FB_OUT1=> OUT1,FB_IN2:=IN2,
FB_OUT2=>OUT2,FB_IN3:= IN3,FB_OUT3=> OUT3,ENO=>B)
■ Example of Entry Method 2
In this example, only parameter variables (including constants) of a new
instance are entered.
Instance_FB(IN1, IN2, IN3, OUT1, OUT2, OUT3)
Instance_FB(IN1, IN2, IN3, OUT1)
• The arguments and return values must be listed in a fixed order.
Input variable 1, Input variable 2, ..., Output variable 1, Output variable 2,
...
• The input variables’ arguments must be at the beginning of the list, or just
after the EN variable if the EN variable is listed.
• An output variable can be omitted if the data is not actually being used
and the output variable is not in the middle of the list of output variables.
Example: Instance_FB(IN1, IN2, IN3, OUT1, OUT3)
In this case, the OUT3 at the end of the list would return the value from
FB_OUT2.
• The EN and ENO data cannot be entered as an argument or return value.
• Specification method 1 cannot be used together with specification method
B in the same function block call statement.
■ Example 2
In the following example, function block 1 calls function block 2, which calcu-
late the average value by calling a function block from within a function block.
Function Block 1
• Variable Table
FB1
Instance_FB1
FB1 (ST)
FB2 (ST)
average := ( input1 + input2 + input3 ) / 3 ;
Program
Average_FB( input1 := data1, input2 := data2,
input3 := data3, average => AVG );
The data1, data2, and data3 values are
passed to input1, input2, and input3.
The average value is
returned in AVG.
Avera
g
e_FB is an instance name with data t
yp
e FUNCTION BLOCK.
Variable type Variable name Data type Passage to/from FB2
Input variable EN BOOL ---
Input variable data1 INT Passed to input1
Input variable data2 INT Passed to input2
Input variable data3 INT Passed to input3
Input variable bCheck BOOL ---
Output variable ENO BOOL ---
Output variable AVG INT Received from average
Internal variable Average_FB FUNCTION BLOCK
Called function block definition:
Function block 2
---
