43
Instance Specifications
Section 2-3
CJ2-series CPU Units
Note Force-setting/resetting is enabled when the following EM banks are specified:
CS/CJ-series CPU Units Ver. 3.0 or Later, and NSJ Controllers
FQM1 Flexible Motion Controllers
CP-series CPU Units
Note DM area of CP1L-L
FB Instance
Area
Default value Applicable memory
areas
Start address End address Size
Non Retain H512 H1407 896 CIO, WR, HR, DM,
EM (See note.)
Retain H1408 H1535 128 HR, DM, EM (See note.)
Timers T3072 T4095 1024 TIM
Counters C3072 C4095 1024 CNT
CJ2H-CPU64(-EIP)/-CPU65(-EIP) EM bank 3
CJ2H-CPU66(-EIP) EM banks 6 to 9
CJ2H-CPU67(-EIP) EM banks 7 to E
CJ2H-CPU68(-EIP) EM banks 11 to 18
FB Instance
Area
Default value Applicable memory
areas
Start address End address Size
Non Retain H512 H1407 896 CIO, WR, HR, DM, EM
Retain H1408 H1535 128 HR, DM, EM
Timers T3072 T4095 1024 TIM
Counters C3072 C4095 1024 CNT
FB Instance
Area
Default value Applicable memory
areas
Start address End address Size
Non Retain 5000 5999 1000 CIO, WR, DM
Retain None
Timers T206 T255 50 TIM
Counters C206 C255 50 CNT
FB Instance
Area
Default value Applicable memory
areas
Start address End address Size
Non Retain H512 H1407 896 CIO, WR, HR, DM (See
note.)
Retain H1408 H1535 128 HR, DM (See note.)
Timers T3072 T4095 1024 TIM
Counters C3072 C4095 1024 CNT
Address CP1L-L
D0000 to D9999 Provided
D10000 to D31999 Not Provided
D32000 to D32767 Provided
