E3X-DA-N
E3X-DA-N
29
Special-purpose through-beam fibers – continued from previous page
: Long-distance mode : Standard mode
: High-speed mode
D “Standard object” measurements were made with E3X-DA-N set to Standard mode. The size of standard object is the same as the
fiber core diameter or the lens diameter for models with a lens.
D “Minimum sensing object” is shown in parentheses below the standard object. The minimum sensing object size was determined
when the E3X-DA-N amplifier received light that exceeded a light incident value of 1000 (set to digital incident level display).
Indicates models that customers can cut to length for their application. Models without this mark are pre-cut by the factory to maintain
their respective specifications.
Applica-
tion
Feature Appearance Applicable
amplifier unit
Sensing distance (mm)
(Values in parentheses
when using the E39-F1
Lens Kit)
Standard
object
(Minimum
sensing
object:
opaque)
Part
number
Permis-
sible
bend-
ing
radius
Heat-
resistant
Side-view; resists
150°C *1; Detects
minute targets; fiber
sheath material:
fluororesin;
Operating ambient
temperature: –40_C
to 150_C
(–40_F to 302_F)
2-mm dia.
E3X-DAj-N
290
230
80
1.0-mm
dia.
(0.01-mm
dia.)
E32-T54 35 mm
Resists 200°C
(392_F) *2;
L-shaped; fiber
sheath material:
stainless steel
3-mm dia.
E3X-DAj-N
1,700
1,300
500
1.7-mm
dia.
(0.01-mm
dia.)
E32-T84S 25 mm
Slot Suitable for film
sheet detection; no
optical axis adjust-
E3X-DAj-N
10
10
10
4.0-mm
dia.
(0.16-mm
E32-G14 25 mm
ment required; easy
to mount
E3X-
DAB11-N
10
10
10
dia.)
Narrow
vision
field
Suitable for detecting
wafers;
3-mm dia.
E3X-DAj-N
2,300
1,900
700
1.7-mm
dia.
(0.01-mm
dia.)
E32-T22S
10 mm
Side-view; suitable
for detecting wafers
3.5 x 3-mm dia.
E3X-DAj-N
1,700
1,300
500
2.0-mm
dia.
(0.01-mm
dia.)
E32-T24S
Area
sensing
Multi-point detection
(4-head)
M3 screw
E3X-DAj-N
700
250
610
2.0-mm
dia.
(0.01-mm
dia.)
E32-M21 25 mm
Detects in a 30-mm
area
30 mm
E3X-DAj-N
2,300
1,800
660
(0.3-mm
dia.) *3
E32-T16W
10 mm
Side-view; suitable
for applications with
limited spatial depth
11 mm
E3X-DAj-N
1,300
1,000
280
(0.2-mm
dia.)
E32-T16J
Area
sensing
Suitable for detecting
over a 10-mm area;
long distance
10 mm
E3X-DAj-N
3,500
2,800
1,000
(0.6-mm
dia.) *3
E32-T16 25 mm
Stable detection for
minute objects in a
wide area; degree of
protection: IP50
11 mm
E3X-DAj-N
1,400
1,100
420
(0.2-mm
dia.) *3
E32-T16P 10 mm
Note: 1. For continuous operation, use the products within the temperature ranging from –40°C to 130°C (–40°F to 266°F)
2. Indicates the heat-resistant temperature at the fiber tip.
3. These figures are for a sensing distance of 100 mm and for detecting over a 10-mm area, or 11-mm area for the E32-T16.
(Figures for the diameter of sensing objects are in the still state.)
