E3X-DA-NE3X-DA-N
32
J SPECIAL-PURPOSE DIFFUSE FIBERS
: Long-distance mode : Standard mode
: High-speed mode
D “Standard object” measurements were made with E3X-DA-N set to Standard mode.
D “Minimum sensing object” is shown in parentheses below the standard object. The values of the minimum sensing object were
obtained at a distance where the smallest object (gold wire) can be sensed with the Diffuse Fiber Unit.
D The E3X-DA-N may continue to receive internal reflective light when it is set to the maximum sensitivity setting. In this case, set the
amplifier to “two-point teaching with or without-object teaching.”
Indicates models that customers can cut to length for their application. Models without this mark are pre-cut by the factory to maintain
their respective specifications.
Applica-
tion
Features Appearance Applicable
amplifier unit
Sensing distance (mm)
(Values measured
using white paper)
Standard
object
(min.
sensing
object
Part number Permis-
sible
bend-
ing
radius
Coaxial M6 coaxial; high-
precision position-
ing accuracy
M6 screw
E3X-DAj-N
400
300
100
500 500
mm
(0.01-mm
dia.)
E32-CC200
25 mm
E3X-DAB11-N
32
25
16
(0.1-mm
dia.)
3-mm dia. coax-
ial; high-precision
positioning accu-
racy
3-mm dia.
E3X-DAj-N
200
150
50
300 300
mm
(0.01-mm
dia.)
E32-D32L
M3 coaxial; high-
precision position-
ing accuracy;
possible to mount
small-spot lens
(E39-F3A-5/F3B/
F3C)
M3 screw
E3X-DAj-N
100
75
25
25 25
mm
(0.01-mm
dia.)
E32-C31
M3 coaxial; high-
precision position-
ing accuracy;
possible to mount
small-spot lens
(E39-F3A-5/F3B/
F3C)
M3 screw
E3X-DAj-N
45
35
10
50 50
mm
(0.01-mm
dia.)
E32-C41
2-mm dia. coax-
ial; high-precision
positioning accu-
racy; possible to
mount small-spot
(0.1 to 0.6 mm
dia.) lens
(E39-F3A)
2-mm dia.
E3X-DAj-N
45
35
10
50 50
mm
(0.01-mm
dia.)
E32-C42
2-mm dia. coax-
ial; high-precision
positioning accu-
racy; possible to
mount small-spot
(0.5 to 1 mm dia.)
lens (E39-F3A)
2-mm dia.
E3X-DAj-N
100
75
25
100 100
mm
(0.01-mm
dia.)
E32-D32
