E3X-DA-N
E3X-DA-N
31
Diffuse fibers – continued from previous page
: Long-distance mode : Standard mode
: High-speed mode
D “Standard object” measurements were made with E3X-DA-N set to Standard mode.
D “Minimum sensing object” is shown in parentheses below the standard object. The values of the minimum sensing object were
obtained at a distance where the smallest object (gold wire) can be sensed with the Diffuse Fiber Unit.
D The E3X-DA-N may continue to receive internal reflective light when it is set to the maximum sensitivity setting. In this case, set the
amplifier to “two-point teaching with or without-object teaching.”
Indicates models that customers can cut to length for their application. Models without this mark are pre-cut by the factory to maintain
their respective specifications.
Ap-
plica-
tion
Features Appearance Applicable
amplifier unit
Sensing distance
(mm)
(Values measured
using white paper)
Standard
object
(min.
sensing
object
Part
number
Permis-
sible
bend-
ing
radius
Flexible Can be bent like
electrical wires
(R1)
M6 screw
E3X-DAj-N
220
170
80
300 300
(0.01-mm
dia.)
E32-D11R
1 mm
M3 screw
E3X-DAj-N
30
10
40
50 50
(0.01-mm
dia.)
E32-D21R
Flexible
(resists
break-
Ideal for mounting
on moving sec-
tions (R4)
M6 screw
E3X-DAj-N
220
170
80
300 300
(0.01-mm
dia.)
E32-D11
4 mm
ing)
M3 screw
E3X-DAj-N
30
10
40
50 50
(0.01-mm
dia.)
E32-D21
M4 screw
E3X-DAj-N
25
90
70
100 100
(0.01-mm
dia.)
E32-D21B
1.5-mm dia.
E3X-DAj-N
30
10
40
50 50
(0.01-mm
dia.)
E32-D22B
To Next Page
