Omron E3X-DA-N - Dimensions; Amplifiers with Male Contacts; Dimensions with Master Connector Connected; Dimensions with Slave Connector Connected

E3X-DA-N
E3X-DA-N
15
Dimensions
Unit: mm (inch)
J AMPLIFIERS WITH MALE CONTACTS FOR E3X-CN CONNECTOR CABLES
E3X-DA6
E3X-DA7
E3X-DA8
E3X-DA9
Hole for optical communications
Operation indicator
(orange)
Incident level display
Threshold level display
Two,
2.4 (0.09)
dia. fiber-
optic cable
ports
8 (0.31)
10.7 (0.42)
64.3 (2.53)
3 (0.12)
10
(0.39)
1.8
(0.07)
14 (0.55)
31.5
(1.24)
38.6 (1.52)
36.7 (1.44)
9.9
(0.39)
3.4
(0.13)
13
(0.51)
5.5 (0.22)
13.05
(0.51)
17.15
(0.67)
4.9 x 3 =
14.7 (0.58)
1.7
4.2
5.1 3.9
1.8
6.2 1.7
Mounting Holes
Two,
M3
16 (0.63)
Dimensions with Master Connector Connected
Dimensions with Slave Connector Connected
4.0 dia.
E3X-CN12:
2.6 dia.
E3X-CN22:
4.0 dia.
64.3 (2.53)
64.3 (2.53)
67.5 (2.66)
67.5 (2.66)
71 (2.80)
71 (2.80)
31.5
(1.24)
31.5
(1.24)
12.95
(0.51)
12.95
(0.51)
17.45
(0.69)
11.55
(0.45)
4 (0.16)
10
(0.39)
4 (0.16)
10
(0.39)
