E3X-DA-N
E3X-DA-N
35
J RETROREFLECTIVE FIBERS
Special-purpose diffuse fibers – continued from previous page
: Long-distance mode : Standard mode
: High-speed mode
D “Standard object” measurements were made with E3X-DA-N set to Standard mode.
D “Minimum sensing object” is shown in parentheses below the standard object. The values of the minimum sensing object were
obtained at a distance where the smallest object (gold wire) can be sensed with the Retroreflective Fiber Unit.
D The E3X-DA-N may continue to receive internal reflective light when it is set to the maximum sensitivity setting. In this case, set the
amplifier to “two-point teaching with or without-object teaching.”
Indicates models that customers can cut to length for their application. Models without this mark are pre-cut by the factory to maintain
their respective specifications.
Applica-
tion
Features Appearance Applicable
amplifier unit
Sensing distance (mm) Standard
object
(min.
sensing
object)
Part number Permis-
sible
bend-
ing
radius
Retrore-
flective
Transparent object
detection; compact
threaded head is
easy to install
M6 screw
Reflector
E39-R3
E3X-DAj-N
10 to 250
10 to 250
10 to 250
35-mm
dia.
(0.1-mm
dia.)
E32-R21
+E39-R3
(supplied)
25 mm
Detects shiny,
transparent and
opaque objects;
block style sensing
head. Operating
ambient tempera-
ture: –25_C to
55_C); degree of
protection: IP66
Reflector
E39-R1
E3X-DAj-N
150 to 1,500
35-mm
dia.
(0.2-mm
dia.)
E32-R16
+E39-R1
(supplied)
