Omron E3X-DA-N - Amplifiers with M8 Connectors; Amplifier Prewired with Cable

E3X-DA-NE3X-DA-N
16
J AMPLIFIERS WITH M8 CONNECTORS
Shown with Mounting Bracket attached
Use Omron XS3F and XS3W connector cables or comparable Brad Harrison NanoChanget cordsets.
E3X-DA14V
E3X-DA44V
Hole for optical
communications
Two, 2.4
(0.09) dia.
fiber-optic
cable
ports
Two, M3
The mounting bracket can
be attached to this side.
28.05 (1.10)
23.95 (0.94)
4.9 x 3 =
14.7 (0.58)
79.5 (3.13)
40 (1.57)
4.9 (0.19)
33
(1.30)
9.9
(0.39)
8 (0.31)
10.7 (0.42)
12
(0.47)
16
(0.63)
Mounting Holes
3.9
(0.15)
3.4
(0.13)
4.3
(0.17)
9.5
(0.37)
23.9 (0.94)
14.4
(0.57)
M8
2.8 (0.11)
11.2
(0.44)
37 (1.46)
16 (0.63)
67.2 (2.65)
11
(0.43)
23.9 (0.94) 16 (0.63)
3.4
(0.13)
5.4
(0.21)
3.4 (0.13) 5.4 (0.21)
J AMPLIFIER PREWIRED WITH CABLE
Shown with Mounting Bracket E39-L143 attached
E3X-DA11-N
E3X-DA21-N
E3X-DA41-N
E3X-DA51-N
E3X-DAB11-N Mark Detection
The mounting bracket can be attached to this side.
Two, 3.2 dia. holes
Mounting bracket E39-L143
SUS304 stainless steel
Mounting Holes
Two,
M3
Hole for optical
communications
Cable (See Note)
Two, 2.4
(0.09) dia.
fiber-optic
cable
ports
8 (0.31)
10.7 (0.42)
16
(0.63)
17.15
(0.68)
13.05
(0.51)
4.9 x 3 =
14.7 (0.58)
64.3 (2.53)3 (0.12)
38.6 (1.52) 5.3 (0.21)
10
(0.39)
10.75
(0.42)
31.5
(1.24)
4.1 (0.16)
22.4 (0.88)
13
(0.51)
16 (0.63)
34.8 (1.37)
2.4 (0.09)
4 (0.16)
9.9
(0.39)
22.4 (0.88) 16 (0.63)
3.4
(0.13)
4.4
(0.17)
Note: With the E3X-DA11-N/DA41-N/DAB11-N, 4-dia., 3-conductor, vinyl-insulated round cables of cross-sectional area 0.45 mm
2
and
insulation diameter of 1.1 dia. are used.
With E3X-DA21-N/DA51-N, 4-dia., 4-conductor, vinyl-insulated round cables of cross-sectional area 0.2 mm
2
and insulation diam-
eter 1.1 dia. are used.
