E3X-DA-N
E3X-DA-N
17
J CONNECTORS
Master Connectors
E3X-CN11
E3X-CN21
See Note
4 (0.16) dia.
2.6
(0.10)
2.9
(0.11)
10.7
(0.42)
10
(0.39)
15.1
(0.59)
6.8
(0.27)
8.4
(0.33)
0.8
(0.03)
14.4
(0.57)
6
(0.24)
6 (0.24)
2000 (6.56 ft)
+50
0
4 (0.16)
30±2 (1.18±0.08)
50 (1.97)
+5
0
10±2
(0.39
±0.08)
Note: E3X-CN11: 4-dia., 3-conductor, vinyl-insulated round cable of cross-sectional area 0.2 mm
2
and insulation diameter 1.1 dia.
E3X-CN21: 4-dia., 4-conductor, vinyl-insulated round cable of cross-sectional area 0.2 mm
2
and insulation diameter 1.1 dia.
Slave Connectors
E3X-CN12
E3X-CN22
See Note
E3X-CN12: 2.6 (0.10) dia.
E3X-CN22: 4 (0.16) dia.
2.6 (0.10)
2.9
(0.11)
10
(0.39)
0.8 (0.03)
14.4
(0.57)
6
(0.24)
6 (0.24)
3
(0.12)
10.7
(0.42)
15.1
(0.59)
6.8
(0.27)
8.4
(0.33)
2000 (6.56 ft)
+50
0
4 (0.16)
30±2 (1.18±0.08)
50 (1.97)
10±2
(0.39
±0.08)
+5
0
Note: E3X-CN12: 2.6 dia., single-conductor, vinyl-insulated round cable of cross-sectional area 0.2 mm
2
and insulation dia. 1.1 dia.
E3X-CN22: 4-dia., 2-conductor, vinyl-insulated round cable of cross-sectional area 0.2 mm
2
and insulation diameter 1.1 dia.
