Omron E3X-DA-N - Remote Control Programmer Details; Optical Communication Head

E3X-DA-NE3X-DA-N
18
J REMOTE CONTROL PROGRAMMER
Optical Communication Head for
Remote Control (included)
AC adapter jack
Communications jack
Connection indicatorMenu indicators
Output indicator
Channel
buttons
Teaching
button
Enter button
Mode
button
Function
button
Battery
indicators
Power supply button
Escape button
Mode display
Channel indicator
Communications jack
M5 ball plunger
Optical commu-
nications position
22 (0.87) 52.8 (2.08)
136
(5.35)
50 (1.97)
10
(0.39)
20
(0.79)
30.3
(1.19)
24.3
(0.96)
9.9
(0.39)
27.7
(1.09)
17.3
(0.68)
1.2
(0.05)
5.1
(0.20)
12.3
(0.48)
13.1
(0.51)
13.2
(0.52)
38.2 (1.50)
31.8 (1.25)
16.3
(0.64)
28.8 (1.13)
36.7 (1.44)
31.2 (1.23)
51.3 (2.02)
5.6 (0.22)
E3X–MC11
