E3X-DA-N
E3X-DA-N
33
Special-purpose diffuse fibers – continued from previous page
: Long-distance mode : Standard mode
: High-speed mode
D “Standard object” measurements were made with E3X-DA-N set to Standard mode.
D “Minimum sensing object” is shown in parentheses below the standard object. The values of the minimum sensing object were
obtained at a distance where the smallest object (gold wire) can be sensed with the Diffuse Fiber Unit.
D The E3X-DA-N may continue to receive internal reflective light when it is set to the maximum sensitivity setting. In this case, set the
amplifier to “two-point teaching with or without-object teaching.”
Indicates models that customers can cut to length for their application. Models without this mark are pre-cut by the factory to maintain
their respective specifications.
Applica-
tion
Features Appearance Applicable
amplifier unit
Sensing distance (mm)
(Values measured
using white paper)
Standard
object
(min.
sensing
object)
Part
number
Permis-
sible
bend-
ing
radius
Side-view
6-mm dia.;
long distance
6-mm dia.
E3X-DAj-N
150
110
50
200 200
mm
(0.01-mm
dia.)
E32-D14L
25 mm
2-mm dia.; small
diameter space-
saving
2-mm dia.
E3X-DAj-N
40
30
10
50 50
mm
(0.01-mm
dia.)
E32-D24
Chemical-
resistant
Teflon-covered
*1; withstands
chemicals and
harsh environ-
ments; Operating
ambient tempera-
ture: –30_C to
70_C
(–22_F to 158_F)
6-mm dia.
E3X-DAj-N
120
95
45
200 200
mm
(0.01-mm
dia.)
E32-D12F 40 mm
Heat-
resistant
Resists 150°C *2;
fiber sheath mate-
rial: fluororesin;
Operating ambi-
ent temperature:
–40_C to 150_C
(–40_C to 302_F)
M6 screw
E3X-DAj-N
300
230
100
200 200
mm
(0.01-mm
dia.)
E32-D51 35 mm
Resists 300°C *3;
fiber sheath
material: stainless
steel;
Operating ambi-
ent temperature:
–40_C to 300_C
(–40_F to 572_F)
M6 screw
E3X-DAj-N
120
90
30
E32-D61
25 mm
Resists 400°C *3;
fiber sheath
material: stainless
steel;
Operating ambi-
ent temperature:
–40_C to 400_C
(–40_F to 752_F)
M4 screw 1.25-mm dia.
E3X-DAj-N
80
60
20
100 100
mm
(0.01-mm
dia.)
E32-D73
Note: 1. Teflon is a registered trademark of the Dupont Company and the Mitsui Dupont Chemical Company for their fluoride resin.
2. For continuous operation, use the products within the temperature ranging from –40°C to 130°C (–40°F to 266°F).
3. Indicates the heat-resistant temperature at the fiber tip.
