E3X-DA-NE3X-DA-N
4
Specifications Table – continued from previous page
Description
Digital output Analog/digital output Mark-detection
M8 connector,
Prewired Connector Prewired Connector Prewired
digital output
Output type
NPN output E3X-DA11-N E3X-DA6 E3X-DA21-N E3X-DA7 E3X-DAB11-N E3X-DA14V
PNP output E3X-DA41-N E3X-DA8 E3X-DA51-N E3X-DA9 --- E3X-DA44V
Shock resistance 500 m/s
2
, for 3 times each in X, Y and Z directions
Degree of protection IP50 IP66
Connection method Prewired,
standard
cable length:
2 m (6.56 ft)
Connector,
E3X–CN
connector
cables
Prewired,
standard
cable length:
2 m (6.56 ft)
Connector,
E3X–CN
connector
cables
Prewired,
standard
cable length:
2 m (6.56 ft)
M8 connector; use
XS3F or XS3W
connector cables
Weight (approx., packed state) 100 g 55 g 100 g 55 g 100 g 100 g
Material
Case PBT
Cover Polycarbonate
J CONNECTOR CABLES
Part number E3X-CN11/21/22 E3X-CN12
Rated current 2.5 A
Rated voltage 50 V
Contact resistance 20 mΩ max. (20 mVDC max., 100 mA max.) (See Note 1)
No. of insertions 50 times (See Note 2)
Material
Housing PBT
Contacts Phosphor bronze/gold-plated nickel
Weight (approx., packed state) 55 g 25 g
Note: 1. The specified value for the contact resistance pertains to the contact resistance between the Connector and the Amplifier Unit,
and the Connector and other neighboring Connectors. It also includes the conductor resistance of the cable.
2. The specified value represents the number of insertions into the Amplifier Unit.
J REMOTE CONTROL PROGRAMMER
Part number E3X-MC11
Power supply voltage Charged with AC adapter
Connection method Connected via adapter
Weight (approx.,
packed state)
580 g (complete kit)
120 g (remote control only)
