E3X-DA-N
E3X-DA-N
7
Output Circuits – continued from previous page
Out-
put
Model Mode
selector
Timing chart State of
output
transistor
Output circuit
PNP E3X-DA51-N
E3X-DA9
LIGHT
ON
(L/ON)
T
ON
OFF
ON
OFF
Incident received
Incident not received
Operation indicator
(orange)
Output
transistor
Load (relay) Operate
Release
(Between blue and black)
Light ON
Load
Load
Brown
Black
Orange
Blue
Control output
12 to
24
VDC
Operation indicator (orange)
Photo-
electric
Sensor
main
circuit
Display
Analog output
1 to 5 V
47Ω
(see note)
DARK
ON
(D/ON)
T
ON
OFF
ON
OFF
Incident received
Incident not received
Operation indicator
(orange)
Output
transistor
Load (relay) Operate
Release
(Between blue and black)
Dark ON
Blue
Note: Load resistance: 10 kΩ min.
J TEACHING FUNCTIONS
Four teaching methods are available to simplify setup and to allow changes in settings on the fly. The E3X-DA-N offers a new feature,
“pinpoint teaching” for positioning
Teaching function
Application Description
Maximum sensitivity setting Use this function for sensing objects without backgrounds or through–
beam sensing. It is ideal for detecting large objects.
Two-point teaching with or without
object
Minute level differences as thin as a piece of paper can be detected.
Detection of semi-transparent objects or the discrimination of object color
is also possible.
One-point teaching without object Set the sensitivity without stopping objects. This function allows automat-
ic detection of differences between objects and the background. Use it to
detect small moving items or thin objects such as gold wire.
Pinpoint teaching for positioning Allows high precision positioning when detecting electronic components
and other small items.
