E3X-DAC-S
10
Chemical-resistant, Oil-resistant
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Bending-resistant
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Heat-resistant
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Type
Sensing
direction
Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Chemical/oil-re-
sistant
Top-view
E32-T12F 2M 850 650 550 280 180 120 100 95
E32-T11F 2M 550 420 360 180 110 80 70 60
Side-view E32-T14F 2M 100 80 70 35 22 16 13 12
Chemical/oil-re-
sistant at 150°C
Top-view E32-T51F 2M 380 300 250 130 80 55 48 44
Type
Sensing
direction
Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Chemical/oil-resistant
Top-view
E32-D12F 2M 22 17 15 6 4.9 3.5 2.9 2
Chemical-resistant cable E32-D11U 2M 42 32 26 11 8.5 6 5 3.5
Size Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
1.5 dia. E32-T22B 2M
70 55 48 40 15 11 9 6
M3 E32-T21 2M
M4 E32-T11 2M 190 140 120 60 40 28 24 20
Square E32-T25XB 2M 55 42 36 30 11 8 7 4.5
Size Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
1.5 dia. E32-D22B 2M
8.8 6.7 5.8 2.1 1.8 1.3 1.1 0.7
M3 E32-D21 2M
3 dia. E32-D221B 2M
19 15 13 4.5 4.1 3 2.4 1.5
M4 E32-D21B 2M
M6 E32-D11 2M 42 32 26 11 8.5 6 5 3.5
Square E32-D25XB 2M 14109332.11.71.1
Heat-resistant temperature Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
150°C E32-T51 2M 200 160 140 70 44 32 26 22
200°C E32-T81R-S 2M 75 60 50 26 16 11 9.5 8.5
350°C E32-T61-S 2M 120 95 80 42 26 19 16 14
Heat-resistant temperature Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
150°C E32-D51 2M 55 42 36 14 11 8.5 7 4.5
200°C E32-D81R-S 2M
2015135432.51.5
350°C E32-D61-S 2M
400°C E32-D73-S 2M 13 10 8.5 3.5 2.8 2 1.7 1.2
