Omron E3X-DAC-S Series User Manual

E3X-DAC-S
22
MODE
MODE
MODE
DOWN
MODE
UP
UP
RUN
RUN
RUN
RUN
6
6-1. Zeroing the Display (Zero Reset)
To return to original value for incident light level:
Set the SET/RUN Mode
Selector to RUN
(Factory-set to RUN)
Set the SET/RUN Mode
Selector to RUN
(Factory-set to RUN)
All key operations can be disabled.
To release the lock:
6-2. Locking the Keys (Key Lock)
LOC ON
LOC OFF
Set the SET/RUN Mode
Selector to RUN
(Factory-set to RUN)
Set the SET/RUN Mode
Selector to RUN
(Factory-set to RUN)
* If a key is pressed while key operations are locked, "LOC" will flash
twice on the display to indicate that
key operations have been disabled.
Press
both buttons
for 3 s.
Press
both buttons
for 3 s.
Press
both buttons
for 3 s.
3 s
MODEMODE
UP DOWN
SET
Initialized.Operation canceled.
INIT YES?
6-4. Initializing Settings (Initialization and User Reset)
Set the SET/RUN Mode
Selector to SET.
INIT NO?
UP DOWN
* Press the UP key right after pressing the MODE key.
* Press the DOWN key right after pressing the MODE key.
*
*
*
MODEMODE
RST USERRST INIT
UP DOWN
MODEMODE
Operation canceled.Settings initialized.
USER NO?USER
The section enclosed by dotted lines applies to user-saved settings.
YES?
UP DOWN
The incident light level on the main display can be set to
0. This is useful when the reference display is to be reset
to zero because the match display and the threshold are
shifted at the same time.
* Change the function to 0RST (zero reset) with the MODE key.
The default setting is 1PNT.
"ON" will flash twice and
key operations will be
disabled.
"OFF" will flash twice and
key operations will be
enabled.
All settings will be initialized and returned to the factory
settings or to a saved state.
Press
both buttons
for 5 s.
6-3. Saving a Set State (Saving User Settings)
* Be sure to register (i.e., teach) the workpiece colors if the detection
functions have been changed.
MODE
MODE
MODE
UP
SET
Operation canceled.
User settings saved.
SAVE NO?
Set the SET/RUN Mode
Selector to SET.
SAVE YES?
UP DOWN
∗
Press
both buttons
for 5 s.
➜ Page 21 Refer to 5. Setting Functions in SET Mode.
Convenient Functions
