Application
Wide Range of
Fiber Heads Available
Select from a wide range of Fiber Heads to match
the workpiece and working space. This makes
installation possible even in small spaces.
Easy and Reliable Applications (Examples)
Detecting Marks
Distinguishing
Semi-transparent Objects
Detecting Black Marks
Distinguishing Trays * Detecting Wafers
Detecting Products on
Conveyors
9 mm
23 mm
20 mm
Many Compact Heads
Because it distinguishes RGB
ratios, detection is highly resistant
to workpiece movement.
Through-beam Fiber Heads are
capable of detecting color differences
in semi-transparent objects.
In Black Mode, black seam tape and
other black marks can be detected
regardless of film color or patterns.
If you teach the conveyor (i.e., the
background), you can detect
workpieces even if they have
different colors, shapes, or gloss.
Workpieces that absorb a specific
wavelength can be detected with
a wide range of wavelengths.
Four-color determination greatly
reduces the work required for line
switchovers.
* Switching banks requires 300 ms.
Long-distance
Fiber Head
E32-A09
General-purpose
Fiber Head
E32-CC200
Compact
Fiber Head
E32-C31
Detection distance:
30 mm
Detection distance:
9 mm
Detection distance:
3 mm
M6 screw
M3 screw
To Next Page
