Omron E3X-DAC-S Series User Manual

E3X-DAC-S
8
Sensing Distance
Threaded Models
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Cylindrical Models
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Flat Models
Through-beam Fiber Units
* These sensing distances are recommended to make the most of the detection capabilities of the Sensor.
Reflective Fiber Units
Sensing direction Size Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Right-angle
M4
E32-T11N 2M
150 110 95 50 30 22 18 16
Straight E32-T11R 2M
Sensing direction Size Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Right-angle
M3 E32-C31N 2M 7.7 6 4.8 2.1 1.6 1.2 0.9 0.7
M6 E32-C11N 2M 35 26 22 9 7.5 5 4.5 3
Straight
M3 E32-C31 2M 17 13 11 4.5 3.7 2.7 2.2 1.5
M6
E32-D11R 2M 42 32 26 11 8.5 6 5 3.5
E32-CC200 2M 60 45 35 16 12974
Size
Sensing
direction
Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
1.5 dia.
Top-view
E32-T22B 2M 70 55 48 40 15 11 9 6
3 dia.
E32-T12R 2M 150 110 95 50 30 22 18 16
Side-view E32-T14LR 2M 55 44 38 19 12 8.5 7 6.5
Size
Sensing
direction
Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
1.5 dia.
Top-view
E32-D22B 2M 8.8 6.7 5.8 2.1 1.8 1.3 1.1 0.7
3 dia.
E32-D221B 2M 19 15 13 4.5 4.1 3 2.4 1.5
E32-D32L 2M 35 26 22 9 7.5 5 4.5 3
Sensing direction Model
Sensing distance (mm)
Opaque object (Translucent object) *
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Top-view E32-T15XR 2M 150 110 95 50 30 22 18 16
Side-view E32-T15YR 2M
55 44 38 19 12 8.5 7 6.5
Flat-view E32-T15ZR 2M
Sensing direction Model
Sensing distance (mm)
White paper
Standard color card (11 colors)
(mutual determination)
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
High-
resolution
mode
Standard
mode
High-speed
mode
Super-high-
speedmode
Top-view E32-D15XR 2M 42 32 26 11 8.5 6 5 3.5
Side-view E32-D15YR 2M
10 7.5 6.5 2.5 2.1 1.5 1.3 0.9
Flat-view E32-D15ZR 2M
