Ordering Information
Amplifier Units
Pre-wired model (Standard cable length 2 m)
* Four-color determination is enabled by switching between banks for two outputs using an external input.
Amplifier Units with Connectors (Amplifier Unit Connectors must be purchased separately.)
Amplifier Unit Connectors (Order Separately) Note: Protector seals are provided as accessories.
Accessories (Order Separately)
Mounting Bracket End Plate
Item Appearance Functions
Model
NPN output PNP output
Standard models Timer, Response speed change E3X-DAC11-S 2M E3X-DAC41-S 2M
Advanced models
(2-color simultaneous
determination)
Standard models + Simultaneous deter-
mination (2 colors), AND/OR output, Re-
mote setting
E3X-DAC21-S 2M E3X-DAC51-S 2M
Advanced models
(4-color determination*)
Standard models + Determination (4 col-
ors), AND/OR output, bank switching
E3X-DAC21B-S 2M E3X-DAC51B-S 2M
Item Appearance Functions
Model
NPN output PNP output
Standard models Timer, Response speed change E3X-DAC6-S E3X-DAC8-S
Item Appearance Cable length No. of conductors Model
Master
Connector
2 m
3 E3X-CN11
Slave
Connector
1 E3X-CN12
Combining Amplifier Units and
Connectors
Amplifier Units and Connectors are sold sep-
arately. Refer to the following tables when
placing an order.
When Using 5 Amplifier Units
Amplifier Unit
Applicable Connector
(Order Separately)
Model NPN output PNP output Master Connector Slave Connector
Standard models E3X-DAC6-S E3X-DAC8-S + E3X-CN11 E3X-CN12
Amplifier Units (5 Units) + 1 Master Connector 4 Slave Connectors
Appearance Model Quantity
E39-L143 1
Appearance Model Quantity
PFP-M 1
