Omron E3X-MDA - Fiber Units with a Narrow Vision Field; Area-Sensing Fiber Units

10 E3X-MDA Super Dual Fiber Sensors
Fiber Units with a Narrow Vision Field
Area-sensing Fiber Units
*1: These figures are for a sensing distance of 300 mm. (Figures for the diameter of sensing objects are in the still state.)
*2: These figures are ones for which detection is possible in each sensing area at a digital incident level of 1,000.
(Figures for the diameter of sensing objects are in the still state.)
Features Appearance Applicable
Amplifier Unit
Sensing distance (mm)
(Parentheses: With E39-F1 Lens
Unit)
Standard object
(min. sensing
object)
(Parentheses:
Opaque object)
Model Permissi-
ble bend-
ing radius
Suitable for detect-
ing wafers
E3X-MDA 1.7-mm dia.
(0.1-mm dia.)
E32-T22S 25 mm
Side-view; suitable
for detecting wafers
E3X-MDA 2-mm dia.
(0.1-mm dia.)
E32-T24S 10 mm
3-mm dia.
1,600
1,250
500
3.5 × 3-mm dia.
1,100
870
350
Features Appearance Applicable
Amplifier Unit
Sensing distance (mm)
(Parentheses: With E39-F1 Lens
Unit)
Standard object
(min. sensing
object)
(Parentheses:
Opaque object)
Model Permissi-
ble bend-
ing radius
Multi-point detec-
tion (4-head)
E3X-MDA 2-mm dia.
(0.1-mm dia.)
E32-M21 25 mm
Detects in a 30-mm
area
E3X-MDA (0.3-mm dia.)
*1
E32-T16W 10 mm
E3X-MDA E32-T16WR 1 mm
Side-view; suitable
for applications with
limited spatial
depth
E3X-MDA (0.2-mm dia.)
*1
E32-T16J 10 mm
E3X-MDA E32-T16JR 1 mm
Suitable for detect-
ing over a 10-mm
area; long distance
E3X-MDA (0.6-mm dia.)
*2
E32-T16 25 mm
Stable for detecting
minute sensing ob-
jects in a wide area
E3X-MDA (0.2-mm dia.)
*1
E32-T16P 10 mm
E3X-MDA E32-T16PR 1 mm
M3 screw
470
360
140
30 mm
1,400
1,100
450
30 mm
1,100
860
340
11 mm
800
650
260
11 mm
600
480
190
10 mm
2,400
1,800
740
11 mm
970
750
300
11 mm
730
560
220
