Omron E3X-MDA - Flexible Fiber Units (Resists Breaking) (R4); Side-View Fiber Units

E3X-MDA Super Dual Fiber Sensors 7
Flexible Fiber Units (Resists Breaking) (R4)
* The optical fiber is 2 m long on each side, so the sensing distance is 4,000 mm.
Side-view Fiber Units
Features Appearance Applicable
Amplifier Unit
Sensing distance (mm)
(Parentheses: With E39-F1 Lens
Unit)
Standard object
(min. sensing
object)
(Parentheses:
Opaque object)
Model Permissi-
ble bend-
ing radius
Ideal for mounting
on moving sections
(R4)
E3X-MDA 1.0-mm dia.
(0.005-mm dia.)
E32-T11 4 mm
E3X-MDA 0.5-mm dia.
(0.005-mm dia.)
E32-T21
E3X-MDA E32-T22B
M4 screw
180 (930)
580 (3,000)
450 (2,300)
M3 screw
45
110
150
1.5-mm dia.
45
110
150
Features Appearance Applicable
Amplifier Unit
Sensing distance (mm)
(Parentheses: With E39-F1 Lens
Unit)
Standard object
(min. sensing
object)
(Parentheses:
Opaque object)
Model Permissi-
ble bend-
ing radius
Long distance;
space-saving
E3X-MDA 1.0-mm dia.
(0.005-mm dia.)
E32-T14L 25 mm
Space-saving
E3X-MDA E32-T14LR 1 mm
Suitable for detect-
ing minute sensing
objects; small di-
ameter
E3X-MDA 0.5-mm dia.
(0.005-mm dia.)
E32-T24 10 mm
Suitable for detect-
ing minute sensing
objects; small di-
ameter
E3X-MDA E32-T24R 1 mm
Screw-mounting
type
E3X-MDA 4-mm dia.
(0.1-mm dia.)
E32-T14 25 mm
3-mm dia.
120
300
390
3-mm dia.
50
130
170
1-mm dia.
70
100
30
1-mm dia.
35
27
10
2,900
2,200
900
