4 E3X-MDA Super Dual Fiber Sensors
Amplifier Unit Connectors
Mobile Console
Item E3X-CN11/21/22 E3X-CN12
Rated current 2.5 A
Rated voltage 50 V
Contact resistance 20 m
Ω max. (20 mVDC max., 100 mA max.)
(The figure is for connection to the Amplifier Unit and the adjacent Connector. It does not include the conductor resistance
of the cable.)
No. of insertions
(destruction)
50 times
(The figure for the number of insertions is for connection to the Amplifier Unit and the adjacent Connector.)
Materials Housing Polybutylene terephthalate (PBT)
Contacts Phosphor bronze/gold-plated nickel
Weight (packed state) Approx. 55 g Approx. 25 g
Item E3X-MC11-S
Supply voltage Charged with AC adapter
Connection method Connected via adapter
Weight (packed state) Approx. 580 g (Console only: 120 g)
Refer to Operation Manual provided with the Mobile Console for de-
tails.
