6 - 33
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-5 Adjustment Level
6
This parameter sets the current for the HS alarm to be output.
hs2
HS Alarm 2
HB and HS alarms must be supported (two CTs).
The HS Alarm Use parameter must be set to ON.
• An HS alarm is output when the leakage current value exceeds the setting of this
parameter.
• When the set value is 50.0, the HS alarm output is turned OFF. When the set value is 0.0,
the HS alarm output is turned ON.
z Related Parameters
Leakage Current 2 Monitor (Adjustment Level): Page 6-32
HS Alarm Use (Advanced Function Setting Level): Page 6-94
HS Alarm Latch (Advanced Function Setting Level): Page 6-94
HS Alarm Hysteresis (Advanced Function Setting Level): Page 6-95
ins
PV Input Shift
Sometimes an error occurs between the process value and the actual temperature. To offset
this, a compensated value can be obtained by adding an input shift value to the input. The
compensated value is displayed as the process value and used for control. The entire input
range is shifted by a fixed rate. If the input shift value is set to −1°C, control will be per-
formed for a value 1°C lower than the measured temperature.
* The decimal point position depends on the Decimal Point parameter setting.
z Related Parameters
Input Type (Initial Setting Level): Page 6-56
inrt
PV Slope Coefficient
This parameter sets a factor to apply to the input to compensate the process value. The
resulting value is displayed as the process value and used in control.
Function
Setting
Setting range Unit Default
0.0 to 50.0 A 50.0
See
See
Function
Setting
Setting range Unit Default
Temperature input: −199.9 to 999.9 °C or °F0.0
Analog input: −1,999 to 9,999* EU 0
See
See
Function
Setting
Setting range Default
0.001 to 9.999 1.000
