6 Parameters
6 - 38
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This parameter sets the hysteresis for ensuring stable operation at the ON/OFF switching point.
of-r
Manual Reset Value
The control must be standard control and 2-PID
control.
The Integral Time parameter must be set to 0.
• This parameter sets the required manipulated variable to remove offset during
stabilization of P or PD control.
z Related Parameters
Integral Time (Adjustment Level): Page 6-36
PID * Integral Time (PID Setting Level): Page 6-47
PID * Manual Reset Value (PID Setting Level): Page 6-48
PID ON/OFF (Initial Setting Level): Page 6-63
hys
chys
Hysteresis (Heating)
Hysteresis (Cooling)
The control must be ON/OFF control.
For the Hysteresis (Cooling) parameter, the control
must be heating/cooling control.
• For standard control, use the Hysteresis (Heating) parameter. The Hysteresis (Cooling)
parameter cannot be used.
• For heating/cooling control, the hysteresis can be set independently for heating/cooling.
The Hysteresis (Heating) parameter is used for the heating side, and the Hysteresis
(Cooling) parameter is used for the cooling side.
z Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-63
Standard or Heating/Cooling (Initial Setting Level): Page 6-64
Function
Setting
Setting range Unit Default
0.0 to 100.0 % 50.0
See
See
Function
Setting
Parameter name Setting range Unit Default
Hysteresis
(Heating)
Temperature input 0.1 to 999.9 °C or °F1.0
Analog input 0.01 to 99.99 %FS 0.10
Hysteresis
(Cooling)
Temperature input 0.1 to 999.9 °C or °F1.0
Analog input 0.01 to 99.99 %FS 0.10
See
See
