6 - 39
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-5 Adjustment Level
6
mv-r
MV at Reset
The control must be set to 2-PID control and the
Reset Operation parameter must be set to stop
control.
• This parameter sets the MV when switching between run status and reset status during
Run/Reset control. However, if the reset operation is set to a fixed SP operation, the MV
at reset is not used.
• The parameter is masked by default and not displayed.
z Related Parameters
Run/Reset (Operation Level): Page 6-14
Parameter Mask Setting (Advanced Function Setting Level): Page 6-110
mV-e
MV at PV Error
The control must be set to 2-PID control or a
Position-proportional Model must be used.
• This parameter sets the MV to use when an input error occurs.
• This parameter is masked by default and not displayed.
z Related Parameters
Close/Floating (Initial Setting Level): Page 6-75
Direct Setting of Position Proportional MV (Advanced Function Setting Level): Page
6-102
Parameter Mask Setting (Advanced Function Setting Level): Page 6-110
Function
Setting
Control method Setting range Unit Default
Standard
Position proportional (Closed and direct setting of
position proportional MV is ON.)
−5.0 to 105.0 % 0.0
Heating/cooling −105.0 to 105.0
Position Proportional
(Floating or direct setting of position proportional MV is
OFF.)
CLOS, HOLD, or
OPEN
None HOLD
See
See
Function
Setting
Control method Setting range Unit Default
Standard
Position proportional (Closed and direct setting of
position proportional MV is ON.)
−5.0 to 105.0 % 0.0
Heating/cooling −105.0 to 105.0
Position Proportional
(Floating or direct setting of position proportional MV is
OFF.)
CLOS, HOLD, or
OPEN
None HOLD
See
See
