Loop Burnout Alarm Section 4-12
Initial Setting Level
3. Press the U Key to set the parameter to 12.
To return to the operation level, press the O Key for at least one second.
Operation Level
4. Press the O Key to move from the operation level to the PID setting level.
PID Setting Level
5. The current PID set number will be displayed. Press the U or D Key to
select PID set 2.
6. Press the M Key to select the PID 2 LBA Detection Time parameter.
7. Press the U Key to set the parameter to 10.
Initial Setting Level
8. Press the O Key for at least three seconds to move to the initial setting
level.
9. Select the Move to Advanced Function Setting Level parameter by press-
ing the M Key. (For details on moving between levels, refer to 4-8 Moving
to the Advanced Function Setting Level.)
Advanced Function Setting Level
10. Press the D Key to enter the password (−169), and move from the initial
setting level to the advanced function setting level.
Advanced Function Setting Level
11. Select the LBA Level parameter by pressing the M Key.
12. Press the U Key to set the parameter to 8.0. (The default is 8.0.)
Advanced Function Setting Level
13. Select the LBA Band parameter by pressing the M Key.
14. Press the U or D Key to set the parameter to 3.0. (The default is 3.0.)
alt1
12
C
25.0
100.0
PV/SP
d.pid
2
Display PID
Selection
2.lba
0
PID 2 LBA
Detection Time
2.lba
10
in-t
5
Input Type
amov
0
Move to Ad-
vanced Function
Setting Level
init
off
Parameter
Initialization
C
lbal
8.0
LBA Level
C
lbal
8.0
C
lbab
3.0
LBA Band
C
lbab
3.0
