Omron E5AN-H User Manual

281
Communications Setting Level Section 5-11
5-11 Communications Setting Level
• Each parameter is enabled when the power is reset.
• Match the communications specifications of the E5@N-H and the host
computer. If multiple devices are connected, ensure that the communica-
tions specifications for all devices in the system (except the Communica-
tions unit number) are the same.
■ Related Parameter
Communications writing (adjustment level): Page 193
psel Protocol Setting
Communications must be supported.
u-no Communications Unit No.
bps Communications Baud Rate
len Communications Data Length
CompoWay/F must be selected as the protocol.
sbit Communications Stop Bits
CompoWay/F must be selected as the protocol.
prty Communications Parity
sdwt Send Data Wait Time
Item Symbol Set values Settings Default
Protocol setting psel cwf, mod CompoWay/F
(SYSWAY), Modbus
cwf
Communications
Unit No.
u-no 0 to 99 0 to 99 1
Communications
baud rate
bps 1.2, 2.4, 4.8, 9.6,
19.2, 38.4, or 57.6
(kbps)
1.2, 2.4, 4.8, 9.6,
19.2, 38.4, or 57.6
(kbps)
9.6
Communications
data length
len 7 or 8 bits 7 or 8 bits 7
Stop bits sbit 1 or 2 bits 1 or 2 bits 2
Communications
parity
prty none, even, odd None, Even, Odd even
Send data wait time sdwt 0 to 99 0 to 99 (ms) 20
See
See
