Adjustment Level Section 5-4
5-4 Adjustment Level
This level is for executing AT (auto-tuning) and other operations, and for set
control parameters.
This Digital Controllers the basic Controller parameters for PID control (pro-
portional band, integral time, derivative time) and heating/cooling control.
To move to the adjustment level from the operation level, press the O Key
once.
• The following parameters are displayed for Controllers with CT Inputs:
Heater current monitors, Leakage current monitors, heater burnout detec-
tions, HS alarms, and heater overcurrent detections.
• Adjustment level parameters can be changed after setting the Operation/
Adjustment Protect parameter to 0. Displays and changing levels are not
possible if the Operation/Adjustment Protect parameter is set to 1 to 3.
Protection is set in the protect level.
Power ON
Operation Level
Adjustment
Level
PID Setting
Level
Bank Setting
Level
Control in progress
Press the O Key
for at least 1 s.
