276
Advanced Function Setting Level Section 5-10
The display below the decimal point in the PV can be hidden for temperature
inputs.
• The PV decimals below the decimal point can be hidden by setting the PV
Decimal Point Display parameter to OFF. When this parameter is set to
ON, the display below the decimal point will appear according to the input
type setting.
â– Related Parameters
Input type (initial setting level): Page 224
• The PV in the No. 1 display for the PV/SP, PV, or PV/Manual MV (Valve
Opening) Screen is alternately displayed in 0.5-s cycles with the control
and alarm status specified for the PV status display function.
â– Related Parameters
Process value/set point, PV (operation level): Page 177
PV/MV (manual MV) (manual control level): Page 221
pvdp PV Decimal Point Display
The input type must be set to tem-
perature input.
Setting range Default
on: ON, off: OFF ON
Function
Setting
See
See
pvst PV Status Display Function
Monitor range Default
off: No PV status display off
manu: MANU is alternately displayed during manual control.
stop: STOP is alternately displayed while operation is stopped.
alm1: ALM1 is alternately displayed during Alarm 1 status.
alm2: ALM2 is alternately displayed during Alarm 2 status.
alm3: ALM3 is alternately displayed during Alarm 3 status.
alm: ALM is alternately displayed when Alarm 1, 2, or 3 is set to ON.
ha: HA is alternately displayed when a heater burnout alarm, HS alarm,
or heater overcurrent alarm is ON.
Monitor
See
See
