18
Overview of System Startup Procedure Section 2-1
When the settings have been completed, the following message will be dis-
played.
Note If the following message is displayed, perform the steps given be-
low.
• Check whether the device supports IP address setting using the Net-
work Configurator (IP address setting with CIP messages). If this
method is not supported, use a different method to set the IP address.
• Repeat the above setting procedure from the very beginning. The IP
address that was set for the device with the Network Configurator us-
ing a CIP message may not be enabled.
Common Procedure 6-3. Setting IP Addresses Using the BOOTP Server
Common Procedure 6-3-1. Enabling BOOTP from the Network
Configurator
1,2,3... 1. Select Tools
−
Setup TCP/IP Configuration to open the Setup TCP/IP
Configuration Dialog Box.
2. Input the current IP address of the device to be set in Target IP Address
Box.
In the New Configuration Area, select the Set the IP address via BOOTP
server Option, and then click the Set to the Device Button.
Input the IP address of
the device to be set.
Input the new IP address
or subnet mask.
Finally, click the Set to
the Device Button.
To Next Page
