Overview of System Startup Procedure Section 2-1
When the settings have been completed, the following message will be dis-
played.
Note If a message like the one shown below is displayed, perform the
steps given below.
Repeat the above setting procedure from the very beginning.
Common Procedure 6-3-2. IP Address Setting Using the BOOTP Server
This procedure uses the BOOTP_DHCP Server distributed by Rockwell Auto-
mation, Inc., as the BOOTP server. (This server can be downloaded from
http://www.ab.com/networks/bootp.html.)
1,2,3... 1. Select All Programs
−
Rockwell Software
−
BOOTP-DHCP Server from
the Windows Start Button to start the BOOTP server.
2. Connect those devices in either BOOTP or DHCP mode to the computer.
For details on how to set BOOTP or DHCP mode, refer to the manual for
each device.
Input the IP address of
the device to be set.
Select Set the IP
address via BOOTP
server.
Click the Set to the
Device Button.
To Next Page
