Omron ERT1 Series

69
Environment-resistive Slave Units Section 5-2
2-B Lit yellow. Output 3 is ON.
Not lit. Output 3 is OFF.
Lit red. Output 3 is short-circuited.
Flashing red. Output 3 is disconnected.
3-A Lit yellow. Output 4 is ON.
Not lit. Output 4 is OFF.
Lit red. Output 4 is short-circuited.
Flashing red. Output 4 is disconnected.
3-B Lit yellow. Output 5 is ON.
Not lit. Output 5 is OFF.
Lit red. Output 5 is short-circuited.
Flashing red. Output 5 is disconnected.
4-A Lit yellow. Output 6 is ON.
Not lit. Output 6 is OFF.
Lit red. Output 6 is short-circuited.
Flashing red. Output 6 is disconnected.
4-B Lit yellow. Output 7 is ON.
Not lit. Output 7 is OFF.
Lit red. Output 7 is short-circuited.
Flashing red. Output 7 is disconnected.
5-A Lit yellow. Output 8 is ON.
Not lit. Output 8 is OFF.
Lit red. Output 8 is short-circuited.
Flashing red. Output 8 is disconnected.
5-B Lit yellow. Output 9 is ON.
Not lit. Output 9 is OFF.
Lit red. Output 9 is short-circuited.
Flashing red. Output 9 is disconnected.
6-A Lit yellow. Output 10 is ON.
Not lit. Output 10 is OFF.
Lit red. Output 10 is short-circuited.
Flashing red. Output 10 is disconnected.
6-B Lit yellow. Output 11 is ON.
Not lit. Output 11 is OFF.
Lit red. Output 11 is short-circuited.
Flashing red. Output 11 is disconnected.
7-A Lit yellow. Output 12 is ON.
Not lit. Output 12 is OFF.
Lit red. Output 12 is short-circuited.
Flashing red. Output 12 is disconnected.
Indicator Color Status Meaning (main error)
