Omron FQ2-S Series User Manual

Controlling Operation and Outputting Data with PLC Link Communications
FQ2-S/CH User’s Manual
for Communications Settings
127
3
Controlling Operation and Outputting Data with an
Ethernet Connection
● Expression Setting Example
This example registers an expression to output the following inspection results for data 0.
Inspection item: 0 Search
Parameters to output: Position X, Position Y, Reference SX, and Reference SY
Multi-point output setting: Multi-point output Check Box selected, Count = 4
Output Results
The expression that is registered for data 0 assigns the data for 16 items (64 bytes) in the output area as shown
below.
Output area data Assigned data
Output data 0 (4 bytes) I0.X[0] (Position X 1st point)
Output data 1 (4 bytes) I0.Y[0] (Position Y 1st point)
Output data 2 (4 bytes) I0.SX[0] (Reference SX 1st point)
Output data 3 (4 bytes) I0.SY[0] (Reference SY 1st point)
Output data 4 (4 bytes) I0.X[1] (Position X 2nd point)
Output data 5 (4 bytes) I0.Y[1] (Position Y 2nd point)
Output data 6 (4 bytes) I0.SX[1] (Reference SX 2nd point)
Output data 7 (4 bytes) I0.SY[1] (Reference SY 2nd point)
Output data 8 (4 bytes) I0.X[2] (Position X 3rd point)
Output data 9 (4 bytes) I0.Y[2] (Position Y 3rd point)
Output data 10 (4 bytes) I0.SX[2] (Reference SX 3rd point)
Output data 11 (4 bytes) I0.SY[2] (Reference SY 3rd point)
Output data 12 (4 bytes) I0.X[3] (Position X 4th point)
Output data 13 (4 bytes) I0.Y[3] (Position Y 4th point)
Output data 14 (4 bytes) I0.SX[3] (Reference SX 4th point)
Output data 15 (4 bytes) I0.SY[3] (Reference SY 4th point)
• The inspection results will be output according to the sorting method that is set for multi-point output for the
inspection item.
• In order to output multiple detection results of the inspection items that can be output their results simultaneously,
from the [Inspection] menu of the targeted inspection item, press [Multi-point output] and select [Yes].
LPR(0,I0.C , I0.X,I0.Y,I0.SX,I0.SY)
Start_number
Number_of_data
(Detection count)
data_A, data_B...data_dFunction
Note
